Allocations

Intro to Allocations

U.S. Non-Federal-Government Allocations

2000 - 2065 kHz
MARITIME MOBILE

US340 NG7

FCC Rule Parts:
Maritime (80)
Private Land Mobile (90)

U.S. Federal Government Allocations

2000 - 2065 kHz
FIXED
MOBILE

US340

ITU Region 1 Allocations

2000 - 2025 kHz
FIXED
MOBILE except aeronautical mobile (R)

5.92 5.103

ITU Region 2 Allocations

2000 - 2065 kHz
FIXED
MOBILE

ITU Region 3 Allocations

2000 - 2065 kHz
FIXED
MOBILE

SpectrumWiki

Amateur Radio 160 m Band (ITU Regions 2 & 3)

Access Broadband over Power Line (Access BPL)

Footnotes

5.103 In Region 1, in making assignments to stations in the fixed and mobile services in the bands 1850-2045 kHz, 2194-2498 kHz, 2502-2625 kHz and 2650-2850 kHz, administrations should bear in mind the special requirements of the maritime mobile service.

5.92 Some countries of Region 1 use radiodetermination systems in the bands 1606.5-1625 kHz, 1635-1800 kHz, 1850-2160 kHz, 2194-2300 kHz, 2502-2850 kHz and 3500-3800 kHz, subject to agreement obtained under No. 9.21. The radiated mean power of these stations shall not exceed 50 W.

US340 The band 2-30 MHz is available on a non-interference basis to Federal and non-Federal maritime and aeronautical stations for the purposes of measuring the quality of reception on radio channels. See 47 CFR 87.149 for the list of protected frequencies and bands within this frequency range. Actual communications shall be limited to those frequencies specifically allocated to the maritime mobile and aeronautical mobile services.

NG7 In the bands 2000-2065, 2107-2170, and 2194-2495 kHz, fixed stations associated with the maritime mobile service may be authorized, for purposes of communication with coast stations, to use frequencies assignable to ship stations in these bands on the condition that harmful interference will not be caused to services operating in accordance with the Table of Frequency Allocations. See 47 CFR 80.371(a) for the list of available carrier frequencies.

SpectrumWiki

Amateur Radio 160 m Band (ITU Regions 2 & 3)

According to the ITU, the propagation characteristics in this band "allow short-range communications during daytime hours, and medium and long-range communications during night-time hours. This band is particularly useful during sunspot minima, when the maximum usable frequency (MUF) is below 3500 kHz."

The band is often referred to as "160 meters", referring to its approximate wavelength.

In the United States, the following 160 m band plan has been adopted by the ARRL, the National Association for Amateur Radio. Some or all of this band plan may apply in other countries as well. By FCC rules, the entire band is available for RTTY, data, phone, and image for General, Advanced, and Extra class operators, although adherence to the band plan is recommended.

ARRL BAND PLAN:

Frequency (kHz)	Use
1800 - 2000	CW
1800 - 1810	Digital Modes
1810	CW QRP
1843-2000	SSB, SSTV, and other wideband modes
1910	SSB QRP
1995-2000	Experimental
1999-2000	Beacons

EXTRA, ADVANCED, AND GENERAL:

Range (kHz)	Authorized Use(s)
1800-2000	RTTY, data, phone, and image

Frequency Bands
Band	Use	Service	Table
1800 - 2000 kHz	Amateur Radio 160 m Band (ITU Regions 2 & 3)	AM	N

Display this entry in a page by itself

Edit

Access Broadband over Power Line (Access BPL)

According to the FCC's definition, Access BPL is "a carrier current system installed and operated on an electric utility service as an unintentional radiator that sends radio frequency energy on frequencies between 1.705 MHz and 80 MHz over medium voltage lines or over low voltage lines to provide broadband communications and is located on the supply side of the utility service’s points of interconnection with customer premises. Access BPL does not include power line carrier systems as defined in § 15.3(t) or In-House BPL as defined in § 15.3(gg)."

Low voltage lines are defined as lines carrying, for example, 240/120 volts from a distribution transformer to a customer's premises. Medium voltage lines carry between 1,000 and 40,000 volts from a power substation to neighborhoods, and may be overhead or underground.

Access BPL is an unlicensed service operated under Subpart G of Part 15 of the FCC's rules. Radiated emission limits from medium voltage lines in the 1.705-30 MHz range must not exceed the limits in 47 CFR 15.209, and those from 30-80 MHz must not exceed the limits in 15.109(b). Systems that operate on low voltage lines must comply with 15.109(a) limits across the entire 1.705-80 MHz range.

When Access BPL systems must use notch filters to protect licensed services, the notch must be at least 25 dB below applicable Part 15 limits in the 1.705-30 MHz band, and at least 10 dB below the limits in the 30-80 MHz band.

There are 12 sub-bands in which Access BPL systems are not allowed to operate anywhere to protect aeronautical (land) stations and aircraft receivers. Those excluded bands are listed in 15.615(f), and are excluded in the list of Access BPL bands in this entry.

Access BPL systems are not allowed to operate within the sub-band 2173.5-2190.5 kHz within 1 km of coast station facilities listed in 47 CFR 15.615(f)(2)(i), to protect the internationally-recognized standard maritime calling frequency of 2182 kHz.

No Access BPL emissions are allowed in the 73.0-74.6 MHz radio astronomy band on overhead medium voltage lines within 65 km of the Very Large Array radio telescope in New Mexico (34 04 43.5N, 107 37 03.82W), or within 47 km of the VLA on underground power lines or overhead low voltage lines.

Access BPL operators must consult at least 30 days in advance when deploying systems near various FCC field offices, aeronautical and maritime stations, radar systems, radio astronomy stations, and research areas. Details are in 47 CFR 15.615(f)(3).

Frequency Bands
Band	Use	Service	Table
1705 - 2850 kHz	Access BPL	-	-
3025 - 3400 kHz	Access BPL	-	-
3500 - 4650 kHz	Access BPL	-	-
4700 - 5450 kHz	Access BPL	-	-
5680 - 6525 kHz	Access BPL	-	-
6685 - 8815 kHz	Access BPL	-	-
8965 - 10005 kHz	Access BPL	-	-
10100 - 11275 kHz	Access BPL	-	-
11400 - 13260 kHz	Access BPL	-	-
13360 - 17900 kHz	Access BPL	-	-
17970 - 21924 kHz	Access BPL	-	-
22000 kHz - 74.8 MHz	Access BPL	-	-
75.2 - 80 MHz	Access BPL	-	-

External Links:

BPL (CommLawBlog)

Display this entry in a page by itself

Edit

Add New...

Related Documents, Links, and Multimedia:

FCC Proceeding (2)

Band Plan (2)

Engineering Data

	Lower Frequency	Center Frequency	Upper Frequency
Frequency	2000 kHz	2032.5 kHz	2065 kHz
Wavelength	149.9 m	147.5 m	145.2 m
Band designator(s)	MF	MF	MF
Isotropic collecting area	1,788.0 m²	1,731.3 m²	1,677.2 m²
Free space loss (1 m)	N/A (near field)	N/A (near field)	N/A (near field)
Free space loss (1 km)	38.5 dB	38.6 dB	38.7 dB
Free space loss (10 km)	58.5 dB	58.6 dB	58.7 dB
Free space loss (100 km)	78.5 dB	78.6 dB	78.7 dB
Free space loss (1000 km)	98.5 dB	98.6 dB	98.7 dB
Free space loss (35,786 km = GEO orbit)	129.5 dB	129.7 dB	129.8 dB
Free space loss (378,370 km = Moon)	150.0 dB	150.2 dB	150.3 dB
